CustomLine shelf truck with electric drive – eurokraft pro 4 shelves
Wheel type
Frame colour
Preferred RAL colour*
*Available in almost all RAL colours – we will produce the product to suit your requirements for an extra charge of only 10%. Please note that the right of return does not apply. Colour representations on the monitor can deviate from the original. Products with a custom colour are not CO2 compensated.
This label from kaiserkraft evaluates products based on a wide range of sustainability criteria
CustomLine shelf truck with electric drive – eurokraft pro 4 shelves
from
£4,190.00
Price / item (Excl. VAT)
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery
- Fast delivery
We will be happy to help you
01442 238000
Monday-Friday 8am-5pm
Ref.
781175
781174
781165
781166
Wheel type
Frame colour
solid rubber
charcoal RAL 7016
solid rubber
light blue RAL 5012
fully-elastic
charcoal RAL 7016
fully-elastic
light blue RAL 5012
Price / item (Excl. VAT)
Select
£4,190.00
£4,190.00
£4,229.00
£4,229.00
Product description
- Ergonomic and smooth travel due to electric drive
- The drive is controlled by means of Bluetooth using the drawbar head
- Replaceable rechargeable battery system for unlimited operating time
- Intuitive operation with perfect steering control
- A component within the modular CustomLine system
- Trolley can be individually customised and flexible to upgrade with accessories
- Little time required for ergonomic adjustment of the working and handle height
- Max. load 500 kg
The CustomLine shelf truck with our e-module, complete with powerful lithium-ion battery and charger. Wireless – the drive is controlled by means of Bluetooth using the drawbar head.
The shelf truck with an electric drive is the perfect solution for the individual requirements encountered in industry and in manufacturing companies. This innovative product, which is a component within our versatile CustomLine product range, offers you flexibility and modularity due to a range of combination options and it can be upgraded with accessories. Promote ergonomic work processes in your company for the well-being of your employees, as the e-module makes it easy and efficient to transport loads of up to 500 kg. The ergonomic handle of the e-module ensures comfortable use, and it can be adapted to different body sizes. The shelf truck is reliable equipment that will help you with your daily work and is flexible to adapt to your needs while boosting efficiency in your company.
E-module
The e-module is characterised by intuitive operation with perfect control for easy transport of loads up to 500 kg. The battery used for the drive consists of a rechargeable lithium-ion battery, the charging status of which is indicated visually on a battery status indicator. The operating time is up to 8 hours per battery charge with average use. The replaceable battery system makes it easy to exchange the empty battery for a fully charged one to ensure uninterrupted operation. The connection between the drawbar head and drive is wireless and uses Bluetooth, which also enables use in fleet operation. The charging time is just 6 hours for a full charge.
The e-module offers easy navigation, supported by fatigue-free operation due to the ergonomically shaped, multifunctional drawbar head. Sturdy, tubular handles ensure it is easy to steer, and the stepless speed control is provided by two thumb switches, with a maximum speed of 4 km/h. If required, a creep speed can be activated, which enables high precision forward and backward travel. Additional safety features include a warning function in the form of a horn on the drawbar head and a belly switch to prevent entrapment when reversing. The integrated foot protection ensures that there is no risk of becoming trapped under the drive. The e-module does not require a certificate of competence for operation, and anti-theft protection is provided by an access control feature secured by a lock on the drive battery.
CustomLine
The intelligent modular principle allows you to change the configuration of the shelf truck with electric drive at any time to suit your individual requirements. Choose from our preconfigured items with three, four or five shelves.* The number of shelves can be increased by adding additional shelves. Plastic shelves provide a secure grip for components to ensure everything stays in place. You can also convert your shelf truck into an assembly trolley for greater versatility. The trolley can be customised due to its modular design. The corner posts with perforated profiles make it easy to secure the shelves at different heights and thereby customise them to suit your components. Change the height of the trolley by combining corner posts of different lengths. Additional shelves and corner posts with perforated profiles are available separately as accessories. The modern design in light blue or charcoal is stylish and offers you even more options for use and colour coding.
For perfect travel comfort in combination with the electric drive, there are two types of tyres to choose from, these being solid rubber wheels or elastic wheels. The e-module can be replaced with a complete set of tyres or be retrofitted to another trolley to suit requirements. It is also available separately as an accessory for retrofitting to the CustomLine assembly trolley and shelf truck.
*Follow the instructions for use
The shelf truck with an electric drive is the perfect solution for the individual requirements encountered in industry and in manufacturing companies. This innovative product, which is a component within our versatile CustomLine product range, offers you flexibility and modularity due to a range of combination options and it can be upgraded with accessories. Promote ergonomic work processes in your company for the well-being of your employees, as the e-module makes it easy and efficient to transport loads of up to 500 kg. The ergonomic handle of the e-module ensures comfortable use, and it can be adapted to different body sizes. The shelf truck is reliable equipment that will help you with your daily work and is flexible to adapt to your needs while boosting efficiency in your company.
E-module
The e-module is characterised by intuitive operation with perfect control for easy transport of loads up to 500 kg. The battery used for the drive consists of a rechargeable lithium-ion battery, the charging status of which is indicated visually on a battery status indicator. The operating time is up to 8 hours per battery charge with average use. The replaceable battery system makes it easy to exchange the empty battery for a fully charged one to ensure uninterrupted operation. The connection between the drawbar head and drive is wireless and uses Bluetooth, which also enables use in fleet operation. The charging time is just 6 hours for a full charge.
The e-module offers easy navigation, supported by fatigue-free operation due to the ergonomically shaped, multifunctional drawbar head. Sturdy, tubular handles ensure it is easy to steer, and the stepless speed control is provided by two thumb switches, with a maximum speed of 4 km/h. If required, a creep speed can be activated, which enables high precision forward and backward travel. Additional safety features include a warning function in the form of a horn on the drawbar head and a belly switch to prevent entrapment when reversing. The integrated foot protection ensures that there is no risk of becoming trapped under the drive. The e-module does not require a certificate of competence for operation, and anti-theft protection is provided by an access control feature secured by a lock on the drive battery.
CustomLine
The intelligent modular principle allows you to change the configuration of the shelf truck with electric drive at any time to suit your individual requirements. Choose from our preconfigured items with three, four or five shelves.* The number of shelves can be increased by adding additional shelves. Plastic shelves provide a secure grip for components to ensure everything stays in place. You can also convert your shelf truck into an assembly trolley for greater versatility. The trolley can be customised due to its modular design. The corner posts with perforated profiles make it easy to secure the shelves at different heights and thereby customise them to suit your components. Change the height of the trolley by combining corner posts of different lengths. Additional shelves and corner posts with perforated profiles are available separately as accessories. The modern design in light blue or charcoal is stylish and offers you even more options for use and colour coding.
For perfect travel comfort in combination with the electric drive, there are two types of tyres to choose from, these being solid rubber wheels or elastic wheels. The e-module can be replaced with a complete set of tyres or be retrofitted to another trolley to suit requirements. It is also available separately as an accessory for retrofitting to the CustomLine assembly trolley and shelf truck.
*Follow the instructions for use
Available in most RAL colours. Only 10 % extra.
Technical data
| Max. load | 500 kg |
|---|---|
| Platform length | 1050 mm |
| Platform width | 700 mm |
| Length | 1050 mm |
| Width | 700 mm |
| Height | 1550 mm |
| Number of levels | 4 pcs. |
| Base plate | plastic |
| Shelf heights | 275/900/Variabel/1550 mm |
| Number of shelves | 4 pcs. |
| Wheel fittings | 2 swivel castors with double stops, 2 fixed castors |
| Wheel diameter | 200 mm |
| Wheel bearing | roller bearing |
| Frame material | steel |
| Platform material | plastic |
| Product type | shelf trucks with electric drive |
| Supplied | flat pack |
Sustainability
Enkelfähig
Enkelfähig product
Enkelfähig refers to multi-generational thinking, and reflects the extent to which a product or service contributes to the emergence of a sustainable, social and fair future in which our grandchildren will still be able to live. Enkelfähig asks the same question of every product: will this product help create a better tomorrow for future generations?
The 2 categories in which this product performs particularly well are listed below.
For more information about the product evaluation and the Enkelfähig Initiative, please visit our Enkelfähig information page.
Enkelfähig refers to multi-generational thinking, and reflects the extent to which a product or service contributes to the emergence of a sustainable, social and fair future in which our grandchildren will still be able to live. Enkelfähig asks the same question of every product: will this product help create a better tomorrow for future generations?
The 2 categories in which this product performs particularly well are listed below.
For more information about the product evaluation and the Enkelfähig Initiative, please visit our Enkelfähig information page.
Circular economy
A circular economy is an economic system in which waste is avoided and resources are used efficiently by recirculating materials, products and waste in closed cycles and reusing them as raw materials or sources of energy for new products.
This product makes a greater contribution to achieving a circular economy. The greater contribution compared to other products is the result of several factors, including the use of hardwearing materials, the ability to be recycled, and the use of recycled materials in the product design. Sustainable packaging is also factored into any assessment within a circular economy.
Innovation and technological progress
This product scores points within its product group due to the use of an innovative product design or innovative materials that advance product sustainability. Compared to other products, the product utilises, for example, material solutions that are more sustainable, the use of an increased share of recycled materials, or an optimised product design that has a positive impact on the recyclability, service life, durability and therefore the general sustainability of the product solution.
